Description

Applications

Suitable for double-sided polishing, deburring, rounding, rust removal, oxide scale removal, cleaning, drying, and rust prevention of workpieces produced by metal stamping, machining, grinding, and powder metallurgy.

Main Features

Automatic Feeding – Cleaning and Drying – Leveling – Flatness Inspection – Visual Inspection – Oiling for Rust Prevention – Static Electricity Removal and Demagnetization – Automatic Receiving

Product Parameters

Applications: Double-sided polishing, deburring, rounding, rust removal, oxide scale removal, cleaning, drying, and rust prevention for metal stamping, machining, grinding, powder metallurgy, and other workpieces.

Processing Range: Length, Width (20-300mm), Thickness (0.2-50mm);

Line Configuration and Process Flow: Automatic feeding (optional) – Front polishing and deburring (single or multi-station optional) – Automatic flipping – Back polishing and deburring (single or multi-station optional) – Demagnetization – Degreasing and cleaning (ultrasonic or water spray optional) – Water spray rinsing (multi-station optional, water-based rust inhibitor added to cleaning water for rust prevention) – Air cutting water – Hot air circulation drying – Automatic receiving (optional). Note: If oil-based rust prevention is required, the rust prevention process is completed after drying. Equipment customization is supported.

Rated power: 32-45KW;

Total weight (approx.): 6T;

External dimensions (L x W x H): 10000-12000*1200mm*2300mm;

Control system: Human-machine interface, PLC programming control, one-button start/stop;

Power supply voltage: Three-phase five-wire, 380V, 50HZ.
